This May 21, 2018 photo shows a Long March-4C rocket carrying relay satellite Queqiao (Magpie Bridge) being launched from southwest China's Xichang Satellite Launch Center. (PHOTO / XINHUA)

BEIJING – China and Saudi Arabia on Thursday jointly unveiled three lunar images acquired through cooperation on the relay satellite mission for Chang'e-4 lunar probe.

This is an important cooperation achievement between China and Saudi Arabia in the relay satellite mission, the China National Space Administration said in a statement.

The relay satellite for the Chang'e-4 lunar probe, named Queqiao or Magpie Bridge, was launched on May 21 and entered the Halo orbit around the second Lagrangian (L2) point of the Earth-Moon system, about 65,000 km from the Moon, at 11:06 am Thursday after a journey of more than 20 days.

An optical camera, developed by the King Abdulaziz City for Science and Technology of Saudi Arabia, was installed on a micro satellite, named Longjiang-2, which was launched together with Queqiao.

The lunar probe is expected to land on the far side of the Moon at the end of the year.

"The satellite is the world's first communication satellite operating in that orbit, and will lay the foundation for the Chang'e-4, which is expected to become the world's first soft-landing, roving probe on the far side of the Moon," said Zhang Hongtai, president of the China Academy of Space Technology (CAST).

The satellite is the world's first communication satellite operating in that orbit, and will lay the foundation for the Chang'e-4, which is expected to become the world's first soft-landing, roving probe on the far side of the Moon

Zhang Hongtai, President, China Academy of Space Technology

READ MORE: China's Chang'e-4 to conduct first lunar experiment

The concept of the Halo orbit around the Earth-Moon L2 point was first put forward by international space experts in 1950s.

While in orbit, the relay satellite can see both the Earth and the far side of the Moon. The satellite can stay in the Halo orbit for a long time due to its relatively low use of fuel, since the Earth's and Moon's gravity balances the orbital motion of the satellite.

"From Earth, the orbit looks like a halo of the Moon, which is where it got its name," said Zhang Lihua, project manager of the relay satellite.

He said the Halo orbit was a three-dimensional irregular curve. It is extremely difficult and complex to maintain the satellite in orbit.

"If there is a tiny disturbance, such as gravitational disturbance from other planets or the Sun, the satellite will leave orbit. The orbit period is about 14 days. According to our current plan, we will conduct orbit maintenance every seven days," Zhang said.

"Queqiao is like a little kid running wild in orbit. If there's even the slightest negligence by controllers on the ground, the satellite will be lost forever," said Guan Bin, a designer for the satellite's control system.

"It's a new type of orbit, we don't have any experience. We ran a number of simulations to make sure the design is feasible and reliable," Zhang said.

In order to set up a communication link between Earth and the planned Chang'e-4 lunar probe, space engineers must keep the satellite stable and control its altitude, angle and speed with high precision.

Next, the team will test the communication function of the relay satellite.

Weighing about 400 kg and with a designed life of three years, the satellite carries several antennas. One, shaped like an umbrella with a diameter of 4.2 meters, is the largest communication antenna ever used in deep space exploration, said Chen Lan, deputy chief engineer of the Xi'an Branch of CAST.

Tidal forces of the Earth have slowed the Moon's rotation to the point where the same side always faces the Earth, a phenomenon called tidal locking. The other face, most of which is never visible from Earth, is the far side or dark side of the Moon, not because it's dark, but because most of it remains unknown.

With its special environment and complex geological history, the far side is a hot spot for scientific and space exploration. The Aitken Basin of the lunar south pole region on the far side has been chosen as the landing site for Chang'e-4. The region is believed to have great research potential.

However, landing and roving require a relay satellite to transmit signals. Establishing a communication link is essential for the success of the Chang'e-4 mission.

The relay satellite is also equipped with a low-frequency radio spectrometer developed by Dutch scientists to help scientists "listen" to the deeper reaches of the cosmos.

The lander and rover of Chang'e-4 will be equipped with instruments developed by Germany and Sweden. China's lunar exploration program will be a new research platform for scientists around the world.

To raise interests of the public in space exploration, the Lunar Exploration and Space Program Center of the CNSA has invited people to write down their hopes for lunar and space exploration, and the relay satellite carries the names of about 100,000 participants and their hopes into deep space.
